Ridgid 1224 Pipe Threading Machine
Ridgid 1224 Pipe Threading Machine The Model 1224 threads a wide range of pipe including black, galvanized and plastic-coated pipe, together with stainless steel, IMC and heavy-wall conduit, as well as rod up to 30 Rockwell C.
Sold per unit. Brand and stock confirmed on your quote.
Catalog Number
- 26097
- 22563
- 92457
- 92462
- 92467
- 26132
- 26142
- 26152
- 26167
- 55447
- 55452
- 57492
- 57497
- 57502
- 57507
- 58712
- 26192
- 31827
- 32237
- 33057
- 33072
- 33077
- 44992
- 45002
- 51005
- 61122
- 26187
- 26212
- 26217
- 26707
- 34157
- 34162
- 34167
- 34577
Not sure of the size? Add it anyway and tell us in the notes.
Same-Day Quote · Delivered nationwide
Details
| Brand | Ridgid |
| Category | Machineries |
| Type | Threading & Machining |
| Sold per | unit |
Full specifications are confirmed with your quote.
Description
- An induction motor helps minimize noise.
- A special capacitor-start / capacitor-run motor allows the 1224 to thread a full range of material where voltage drop is experienced.
- 1/4"-2" Universal Die Head; 2 1/2"-4" receding die head allows cutting of tapered or straight NPT/NPSM or BSPT/BSPP threads.
- Constant and proper lubrication of dies and workpiece with through-head oiling.
Specifications
Nominal Pipe Capacity 1/4"-2" (6mm-100mm) @ 36 RPM, 2-1/2"-4" (65mm-100mm) @ 12 RPM, 4"-6" (100mm-150mm) with 161 Geared Threader. Bolt Capacity 1/4"-2" (6mm-50mm). Motor Control Reverse/off/forward, heavy-duty rotary-type and integral foot switch. Gear Box Two-speed gear box with a 3:1 ratio. Chuck Hammer-type with replaceable rocker-action jaw inserts. Rear Centering Device Cam action. Oiling Pump Self-priming, gerotor-type, automatic-reversing, constant-flow. Oiling Through die head CATALOG NUMBER MODEL NO. DESCRIPTION DIE HEAD VOLTAGE (V) POWER WEIGHT (kg).
