Raijin RDWSPUMP Submersible Deep Well Pump

Product details

Built with durable internal components and brass inlet, outlet, and oil chamber construction, it ensures long-term reliability in continuous deep well operation. Key Benefits • High head lifting capacity for deep underground water sources • Single-phase operation compatible with standard power supply • Durable brass fittings for improved corrosion resistance and service life Product Overview The Raijin RDWSPUMP series is engineered to provide stable water pressure and efficient pumping from deep bore wells where surface pumps are not suitable. With multiple horsepower options, each model supports different depth and flow requirements while maintaining energy-efficient performance.

Its robust motor design, long power cable, and precision-built internal system make it ideal for household water supply, irrigation networks, and small-scale utility distribution. Ideal Applications • Residential deep well water supply • Agricultural irrigation systems • Small commercial water extraction Technical Specifications (General) Voltage 220–240V Frequency 50/60Hz Phase Single Phase Cable Length 30 meters Construction Brass outlet, inlet, and oil chamber Model – RDWSPUMP370 Power 0.5HP / 370W Max Head 51 meters Max Flow 2.

1 m³/hr Matching Well Diameter 2" Model – RDWSPUMP750 Power 1.0HP / 750W Max Head 96 meters Max Flow 3.1 m³/hr Matching Well Diameter 2.

5" Model – RDWSPUMP1100 (1.5HP) Power 1.5HP / 1100W Max Head 132 meters Max Flow 3.

6 m³/hr Matching Well Diameter 3" Model – RDWSPUMP1500 (2.0HP) Power 2.0HP / 1500W Max Head 164 meters Max Flow 3.

6 m³/hr Matching Well Diameter 3" Model Pricing Model / Size.
