Nitto Kohki CB-01 Pneumatic Air Circuit Beveler / Radial Chamfering Tool

Nitto Kohki CB-01 Pneumatic Air Circuit Beveler / Radial Chamfering Tool Pneumatic Radial Chamfering Tool - Ideally suited for chamfering machine and mold component parts - Only requires a 6.8 mm diameter hole for chamfering - Two 3-sided indexable inserts provide a cost effective way to get a smooth, chatter free finish - Aluminum and stainless steel can also be processed with optional indexable insert Model : CB-01 Air Pressure MPa(kgf/cm2): 0.6 (6) Air Consumption(No-load) m3/min : 0.15 Free Speed min-1(rpm): 28000 Chamfering Capacity Mild Steel : Up to 1 mm Chamfer Stainless Steel* : Up to 0.5 mm Chamfer Aluminum* : Up to 1 mm Chamfer Chamfer Angle : 45 degree Minimum Workpiece Thickness mm : 1.5 (0.5 mm Chamfer) Inlet Size : Rc 1/4 Mass (Weight) kg : 0.5 *Optional indexable insert is required. Chamfering BEVELER (Pneumatic) Chamfer Edge Curve (Mild Steel) Max. Chamfering Capacity 1C (Stainless Steel) Max. Chamfering Capacity 0.5 C (Aluminum) Max. Chamfering Capacity 1C Chamfer Angle 45 degree Air Consumption (No-load) 0.15 m3/min CE CE.

Sold per unit. Brand and stock confirmed on your quote.
