Maxlift Construction Pulley Block Double
Maxlift Construction Pulley Block Double is a double sheave pulley block designed for compatible lifting, pulling, and wire rope handling applications in construction sites, workshops, warehouses, fabrication shops, and industrial material handling areas. Available in multiple load capacities from 0.
- Brand
- Maxlift
- Category
- General Hardware
- Sold per
- pc
- Pricing
- Request a quote (RFQ)
- Delivery
- Nationwide, same-day quote
Product details
25 tons to 2 tons, it supports different wire rope sizes and sheave sizes depending on the required lifting or pulling setup. Key Benefits • Double construction pulley block designed for compatible lifting and pulling applications. • Available in multiple S.
25 tons to 2 tons. • Double sheave design helps support selected wire rope lifting and rigging setups. • Supports different sheave sizes and wire rope sizes depending on job requirements.
• Useful for construction sites, warehouses, workshops, fabrication shops, and industrial handling areas. • Ideal for material handling, jobsite lifting support, wire rope pulling, and general rigging applications. Product Overview The Maxlift Construction Pulley Block Double is designed for users who need a double pulley block for compatible wire rope lifting and pulling systems.
Its double sheave design helps guide wire rope during selected load handling, construction, and material movement applications. With multiple model options available, users can choose the correct S.W.
L., sheave size, wire rope size, and overall size based on their lifting and rigging requirements. Ideal Applications • Construction lifting support • Wire rope pulling applications • Warehouse material handling • Workshop and fabrication use • Rigging support applications • Industrial maintenance work • General material handling tasks Technical Specifications Brand Maxlift Product Type Construction Pulley Block Double Design Type Double Pulley Block Recommended Use Construction lifting support, wire rope pulling, rigging support, material handling, warehouse use, workshop use, and industrial applications Available Variants Model Details LPB2-D S.
25 Tons, 2" Sheave Size, 6mm Wire Rope Size, 225 x 60 x 65mm Overall Size — LPB3-D S.W.L.
0.50 Tons, 3" Sheave Size, 8mm Wire Rope Size, 286 x 87 x 77mm Overall Size — LPB4-D S.W.
L. 1 Ton, 4" Sheave Size, 10mm Wire Rope Size, 311.5 x 112 x 88mm Overall Size — LPB5-D S.
5 Tons, 5" Sheave Size, 13mm Wire Rope Size, 410 x 140 x 100mm Overall Size — LPB6-D S.W.L.
2 Tons, 5" Sheave Size, 16mm Wire Rope Size, 442.5 x 168 x 146mm Overall Size — What’s Included • 1 selected Maxlift Construction Pulley Block Double.
