Makita TW009GZ 40V Cordless Brushless Impact Wrench 1" (25.4mm) 4000Nm X
- Square Drive: 25.4mm / 1in. Maximum
- Fastening Torque: 3,150Nm / 2,323ft-lbs
- Sound Pressure Level: 101dB(A)
- Vibration Level: 37.5m/s² Vibration Uncertainty K 1.6m/s²
Sold per unit. Brand and stock confirmed on your quote.
Specifications
| Brand | Makita |
| Model | TW009GZ |
| Product Type Cordless Brushless Impact Wrench Battery Platform | Makita 40 Vmax XGT |
| Motor Type Brushless Motor | Anvil |
| Type | Short Anvil |
| Square Drive | 25.4mm / 1in. Maximum |
| Fastening Torque | 3,150Nm / 2,323ft-lbs |
| Standard Bolt | M27–M45 / 1-1/8–1-7/8in. High-Strength Bolt M20–M33 / 3/4–1-3/8in. |
| Weight Dimensions | with BL4050F 435 × 135 × 297mm |
| Sound Pressure Level | 101dB(A) |
| Sound Power Level | 109dB(A) Noise Uncertainty K 3dB(A) |
| Vibration Level | 37.5m/s² Vibration Uncertainty K 1.6m/s² |
Description
The Makita TW009GZ 40V Cordless Brushless Impact Wrench 1" 4,000Nm XGT (Bare) is an ultra-high-torque fastening tool designed for heavy-equipment maintenance, industrial machinery, structural bolting, construction, and other demanding applications. Its Makita brushless motor delivers up to 3,150Nm of fastening torque and 4,000Nm of nut-busting torque for loosening large, tightly secured fasteners.
Key Benefits
- Delivers up to 3,150Nm of maximum fastening torque for demanding large-bolt applications.
- Produces up to 4,000Nm of nut-busting torque for loosening heavily tightened or seized fasteners.
- Electronic four-stage impact-power selection allows the output to be matched to the bolt and application.
- Forward and reverse auto-stop modes help reduce overtightening and uncontrolled fastener removal.
- Ring illumination LED reduces socket shadows for improved visibility around the fastener.
- Tool-free adjustable side handle supports controlled operation from different working positions.
Product Overview
The Makita TW009GZ is a short-anvil 1-inch cordless impact wrench powered by the Makita 40 Vmax XGT battery platform. It combines extremely high fastening performance with the portability of a cordless tool, making it suitable for tasks traditionally completed using large pneumatic impact wrenches. The electronic four-stage impact-power selector provides Max, Hard, Medium, and Soft settings. Each setting adjusts the rotational speed, impact rate, and available fastening torque to suit different bolt sizes and materials. The auto-stop system operates in both forward and reverse rotation. Multiple reaction-time settings help the tool stop or slow automatically after detecting changes in impact operation, supporting more controlled fastening and loosening.
Ideal Applications
- Heavy-equipment repair and maintenance
- Industrial machinery assembly and servicing
- Large structural bolt installation and removal
- Counterweight removal and installation
- Construction, mining, transport, and plant maintenance
Key Features
Four-Stage Impact Selection Allows the speed, impact rate, and fastening output to be adjusted according to the application. Forward / Reverse Auto-Stop Provides selectable automatic stopping or slowing behaviour for controlled fastening and loosening. Full-Speed Mode Reaches maximum speed with reduced trigger travel to help minimise fatigue during repeated operation. Ring Illumination LED Surrounds the drive area to reduce socket shadows and improve workpiece visibility. Tool-Free Side Handle Can be installed around the tool and adjusted without requiring a separate tool. XPT Protection Helps improve resistance against dust and moisture in demanding working environments. Tool Hanger Ring Allows the impact wrench to be suspended from approved pipes, hooks, or storage points. Bare-Tool Note: The TW009GZ is supplied without a battery and charger. Use a compatible Makita 40 Vmax XGT battery and charger, sold separately.
What’s Included
- 1 Makita TW009GZ 40 Vmax XGT Cordless Brushless Impact Wrench
- 1 Tool-Free Adjustable Side Handle
- 1 Tool Hanger Ring Battery, charger, impact socket, O-ring, retaining pin, and carrying case are not included unless specifically stated.
