Grundfos Aquastat Thermostatic Switch For Circulator Pump
Brand: Grundfos
Thermostatic switch, Clip-on thermostatic control for the UP/S 100 series circulators. Allows the pump to automatically turn on and off at a specific temperature range. Once it reached the low temperature of hot water line, it will re-circulate tepid water back to electric storage heater.
- Brand
- Grundfos
- Category
- Pumps & Motors
- Subcategory
- Circulation Pumps
- Sold per
- unit
- Pricing
- Request a quote (RFQ)
- Delivery
- Nationwide, same-day quote
Same-Day Quote · brand, spec & stock confirmed · delivered nationwide
Product details
Specifications Type Bi-metallic disc, snap on Enclosure Environmentally sealed Mounting Clip-on mount for 3/4” I.D. Tube (7/8” O.
D.) Contact rating 5 A @ 240 VAC, 60 Hz resistive Temperature rating pump switches on - 105±5°F (40±2°C) pump switches off - 115±5°F (46±2°C) Leads 2 leads, AWG 18, 14” 12”, black insulation, silicon epoxy over-mold. 1/2” strip length 1 Year Service Warranty.
