Grundfos Aquastat Thermostatic Switch For Circulator Pump
Thermostatic switch, Clip-on thermostatic control for the UP/S 100 series circulators. Allows the pump to automatically turn on and off at a specific temperature range. Once it reached the low temperature of hot water line, it will re-circulate tepid water back to electric storage heater.
Sold per unit. Brand and stock confirmed on your quote.
Details
| Brand | Grundfos |
| Category | Pumps & Motors |
| Type | Circulation Pumps |
| Sold per | unit |
Full specifications are confirmed with your quote.
Description
Specifications
Type Bi-metallic disc, snap on Enclosure Environmentally sealed Mounting Clip-on mount for 3/4” I.D. Tube (7/8” O.D.) Contact rating 5 A @ 240 VAC, 60 Hz resistive Temperature rating pump switches on - 105±5°F (40±2°C) pump switches off - 115±5°F (46±2°C) Leads 2 leads, AWG 18, 14” 12”, black insulation, silicon epoxy over-mold. 1/2” strip length 1 Year Service Warranty.
