Details
| Category | Pumps & Motors |
| Type | Submersible Pumps |
| Sold per | unit |
Full specifications are confirmed with your quote.
Description
Features
- Compact Size, light weighted, easy operation and easy to dismantle
- IP68 protection, F class insulation
- High Efficiency motor
- Equipped with Motor overload protector
Applications
- Basement drainage, rainwater effluent and accumulated water drainage
- Suitable for PH 6~9 waste water Model EA-03 EA-05 EA-10 EA-20 EA-30 Power 1/3HP 1/2 HP 1 HP 2HP 3HP Phase 1 1 1 1 1 Voltage 220V/60Hz 220V/60Hz 220V/60Hz 220V/60Hz 220V/60Hz Current 2A 3A 6A 12A 18A Discharge dia. 40mm 50mm 50mm 80mm 80mm Max Head 7m 10m 13m 17m 20m Max Capacity 100 l/min 280 l/min 345 l/min 630 l/min 700 l/min.
